Tiny Giants for ADAS/AD Systems

ADAS and AD systems place very high demands on the reliability of the components. That’s why TDK has developed the CLT32 product series for inductors used in power management units. This innovative and extremely compact series is setting new standards with regard to reliability, miniaturization and electrical parameters.

A compact footprint of 3.2 mm x 2.5 mm and an insertion height of 2.5 mm makes these SMT power inductors extremely compact. They are designed for a temperature range from -40°C to +165°C including self-heating.



  Part Number Description View Details
Shielded Molded Inductor CLT32-55N 55 nH Shielded Molded Inductor 28 A 1mOhm 4-SMD

View Details
Shielded Molded Inductor CLT32-R31 310 nH Shielded Molded Inductor 12.1 A 5.3mOhm 4-SMD

View Details
Shielded Molded Inductor CLT32-17N 17 nH Shielded Molded Inductor 45 A 0.39mOhm 4-SMD

View Details
Shielded Molded Inductor CLT32-42N 42 nH Shielded Molded Inductor 28 A 1mOhm 4-SMD

View Details

View More





Frequently Asked Questions

What are the strong points of CLT32 compared to conventional inductor technologies?

Why should I use CLT32 instead of other power inductor series?

What properties characterize the magnetic molding compound?

Will there be other CLT sizes?



Benefits

Outstanding electrical performance

  • High Isat up to 60A
  • Ultra-low RDC
  • Very high efficiency thanks to low AC losses
  • Low saturation drift at high temperature
  • ESD tested up to 2 kV to AEC-Q200
  • Temperature range up to 165 °C
  • Wide frequency range up to 10 MHz

Extremely compact size

  • Dimensions of only 3.2 x 2.5 x 2.5 mm
  • Highest current handling capability in this size
  • Competitor solutions with similar electrical performance have 2 to nearly 4 times larger footprints
  • CLT32 offers significant PCB space and cost-saving potential

High reliability due to

  • No internal connections
  • Thick copper structure
  • Best insulation system
  • Similar CTE of the different materials
  • Low thermal stress



Automotive application of CLT32

Applications

The compact and highly robust CLT32 inductors are ideal for use in safety-critical automotive applications like ADAS/AD. High-performance processors used in these fields require currents in the double-digit ampere range.



Product Resources

ADAS and AD systems place very high demands on the reliability of the components. With the new CLT32 power inductors, TDK has developed a completely new product series for power management units that sets new standards in reliability, miniaturization and electrical parameters.
